Topics:

• Remove or uninstall oven door on M Series Wall Oven
• Can the oven door be removed to make installation easier?

Answer:

It is strongly recommended to have Factory Certified Service remove an oven door. Performance may be affected if the door is not properly installed.

• The M Series Wall Oven door is not adjustable.

Required Tools:

• T-25 Torx bit screwdriver

Oven Door Removal:

1. Rotate hinge lock towards oven door to engage door locks on both hinges.
2. Using the screwdriver, remove two door-retaining screws as shown below.
3. Pull door away from unit.

Oven Door Installation:

1. Insert the door hinges into the frame openings.
2. Rotate the hinge latches to the closed position.
3. Open and close the door completely to ensure it is properly installed.
